Advanced Technology Amorphous Transformer Core For Industrial Magnet

Brand Name: CAREFUL
Model Number: UT
MOQ: 1000 pieces
Price: $0.50-12.56/pieces
Detail Information
Place of Origin:
Zhejiang, China
Certification:
RoHS
Features:
Industrial Magnet
Type:
Wireless Charging Coils
Application:
Industrial Magnet
Brand:
Careful
Supplier Type:
Factory
Tolerance:
20%
Package Type:
Carton
Media Available:
Careful Catalog
Function:
Industrial Magnet
Mounting Type:
Through Hole
Package / Case:
Carton
Material - Core:
Amorphous
Sample:
Free Charge
Material:
Many For Selection
MOQ:
10 Pcs
Package:
Carton
AL:
2-5000
Packaging Details:
Certain pieces of items into one polybag, several polybags into one export carton.
Pallet could be arranged if required!
Supply Ability:
100000 Piece/Pieces per Month
Highlight:

advanced amorphous core

,

advanced amorphous transformer core

,

industrial amorphous core

Product Description
China factory careful company Advanced technology Amorphous transformer core

Products Description
Advanced Technology Amorphous Transformer Core For Industrial Magnet 0
Advanced Technology Amorphous Transformer Core For Industrial Magnet 1
Advanced Technology Amorphous Transformer Core For Industrial Magnet 2
Advanced Technology Amorphous Transformer Core For Industrial Magnet 3
Advanced Technology Amorphous Transformer Core For Industrial Magnet 4
Item
Value
Place of Origin
China

Zhejiang
Brand Name
Careful
Model Number
T
Type
Soft
Composite
Amorphous
Shape
Coil
Application
Industrial Magnet
Tolerance
±10%
Certificates
ISO9001-2015
Permeability
>100000
Material
Amorphous&Nanocrystalline





RH Specifications Dimensions:mm
A B C
10×17.5×5 10±0.4 17.5±0.5 5±0.4
10×20×4.2 10±0.4 20±0.5 4.2±0.4
10×20×5 10±0.4 20±0.5 5±0.4
10×20×5.5 10±0.4 20±0.5 5.5±0.4
10×20×6 10±0.4 20±0.5 6±0.4
10×20×6.35 10±0.4 20±0.5 6.35±0.4
10×20×6.5 10±0.4 20±0.5 6.5±0.3
10×23×5 10±0.4 23±0.5 5±0.3
10×23×6.5 10±0.4 23±0.5 6.5±0.3
10×25×5.5 10±0.4 25±0.6 5.5±0.4
10.1×11.5×6.5 10.1±0.4 11.5±0.4 6.5±0.3
10.1×13.5×6.35 10.1±0.4 13.5±0.4 6.35±0.3
10.3×11.5×5 10.3±0.4 11.5±0.5 5±0.4
10.5×12×5.5 10.5±0.4 12±0.5 5.5±0.4
10.5×13.5×6.5 10.5±0.4 13.5±0.5 6.5±0.4
10.5×14×6 10.5±0.4 14±0.5 6±0.4
10.5×14×7.3 10.5±0.4 14±0.5 7.3±0.4
10.5×15×5.6 10.5±0.4 15±0.5 5.6±0.4
10.5×15×6.5 10.5±0.4 15±0.4 6.5±0.3
10.5×15×7.3 10.5±0.4 15±0.5 7.3±0.4
10.5×20×5.5 10.5±0.4 20±0.5 5.5±0.4
10.5×20×6 10.5±0.4 20±0.5 6±0.4
10.5×20×6.5 10.5±0.4 20±0.5 6.5±0.4
10.5×20×7.3 10.5±0.4 20±0.5 7.3±0.4
10.5×25×5.6 10.5±0.4 25±0.5 5.6±0.3
10.5×25×6.5 10.5±0.4 25±0.5 6.5±0.3
10.5×28.5×5.5 10.5±0.4 28.5±0.7 5.5±0.4
10.5×30×6.5 10.5±0.4 30±0.6 6.5±0.4
11×13×7.5 11±0.4 13±0.4 7.5±0.3
11×20×5 11±0.5 20±0.5 5±0.4
11×25×5 11±0.5 25±0.6 5±0.4
11×30×5 11±0.4 30±0.6 5±0.3
11.5×18.5×5 11.5±0.5 18.5±0.5 5±0.4
11.5×19.5×5.6 11.5±0.4 19.5±0.4 5.6±0.3
11.5×20×5 11.5±0.5 20±0.5 5±0.4
11.5×20.5×5 11.5±0.4 20.5±0.5 5±0.3
11.5×23×5.2 11.5±0.4 23±0.5 5.2±0.3
11.5×25×5 11.5±0.5 25±0.6 5±0.4
11.5×30×5 11.5±0.5 30±0.6 5±0.4
11.8×15×5 11.8±0.4 15±0.4 5±0.3
11.8×15×7.3 11.8±0.5 15±0.5 7.3±0.4
11.8×15×7.5 11.8±0.4 15±0.4 7.5±0.3
11.8×20×5 11.8±0.4 20±0.5 5±0.3
12×12.5×8.5 12±0.5 12.5±0.5 8.5±0.4
12×12.7×5.6 12±0.4 12.7±0.4 5.6±0.3
12×12.7×6 12±0.5 12.7±0.5 6±0.4
12×12.7×6.5 12±0.5 12.7±0.5 6.5±0.4
12×13×8 12±0.5 13±0.5 8±0.4
12×13.8×6.5 12±0.4 13.8±0.4 6.5±0.3
12×14×6 12±0.4 14±0.4 6±0.3
12×15×5.5 12±0.5 15±0.5 5.5±0.4
12×15.5×5.6 12±0.5 15.5±0.5 5.6±0.4
12×15×6.5 12±0.5 15±0.5 6.5±0.4
12×15×7.3 12±0.5 15±0.5 7.3±0.4
12×15×8 12±0.5 15±0.5 8±0.4
12×15×8.5 12±0.5 15±0.5 8.5±0.5
12×15.5×8 12±0.4 15.5±0.4 8±0.3
12×16.5×6.5 12±0.5 16.5±0.5 6.5±0.4
12×16×8.5 12±0.4 16±0.4 8.5±0.3
12×17.5×6.5 12±0.5 17.5±0.6 6.5±0.4
12×19×5.6 12±0.5 19±0.6 5.6±0.4
12×20×3.5 12±0.5 20±0.6 3.5±0.4
12×20×3.6 12±0.5 20±0.6 3.6±0.4
12×20×4 12±0.5 20±0.5 4±0.4
12×20×4.5 12±0.5 20±0.5 4.5±0.4
12×20×5 12±0.5 20±0.5 5±0.4
12×20×5.2 12±0.4 20±0.5 5.2±0.3
12×20×5.6 12±0.5 20±0.5 5.6±0.4
12×20×5.8 12±0.4 20±0.5 5.8±0.3
12×20×6 12±0.5 20±0.5 6±0.4
12×20×6.5 12±0.5 20±0.5 6.5±0.4
12×20×7 12±0.4 20±0.5 7±0.3
12×20×7.3 12±0.5 20±0.5 7.3±0.4
12×20×8.5 12±0.5 20±0.5 8.5±0.4
12×21×6.5 12±0.4 21±0.5 6.5±0.3
12×22×5.6 12±0.4 22±0.5 5.6±0.3
12×23×3.5 12±0.5 23±0.6 3.5±0.4
12×23×4.5 12±0.5 23±0.6 4.5±0.4
12×23×5.6 12±0.5 23±0.6 5.6±0.4
12×23×6.5 12±0.5 23±0.6 6.5±0.4
12×23×7.9 12±0.5 23±0.6 7.9±0.4
12×24.5×5.6 12±0.5 24.5±0.6 5.6±0.4
12×25×3.5 12±0.4 25±0.5 3.5±0.3
12×25×4.5 12±0.4 25±0.5 4.5±0.3
12×25×5.6 12±0.5 25±0.6 5.6±0.4
12×25×6.4 12±0.4 25±0.5 6.4±0.3
12×25×6.5 12±0.4 25±0.5 6.5±0.3
12×25×7.3 12±0.5 25±0.6 7.3±0.4
12×25.4×5.2 12±0.5 25.4±0.6 5.2±0.4
12×25.4×6.5 12±0.4 25.4±0.5 6.5±0.3
12×25.5×5.6 12±0.4 25.5±0.5 5.6±0.3
12×26×4.5 12±0.4 26±0.5 4.5±0.3
12×26×7.3 12±0.5 26±0.7 7.3±0.4
12×27×7.9 12±0.4 27±0.5 7.9±0.3
12×28.5×5.6 12±0.5 28.5±0.7 5.6±0.4
12×28.5×6.5 12±0.5 28.5±0.7 6.5±0.4
12×28.5×8 12±0.5 28.5±0.7 8±0.4
12×30×5 12±0.5 30±1 5±0.4
RH Specifications Dimensions:mm
A B C
12×30×5.6 12±0.5 30±1 5.6±0.4
12×30×8 12±0.4 30±0.6 8±0.3
12×32×6 12±0.4 32±0.6 6±0.3
12×40×6 12±0.5 40±0.7 6±0.4
12.1×15.5×7.3 12.1±0.5 15.5±0.5 7.3±0.4
12.2×27×7.9 12.2±0.5 27±0.7 7.9±0.4
12.2×28.5×7.9 12.2±0.5 28.5±0.7 7.9±0.4
12.3×12.5×5 12.3±0.5 12.5±0.5 5±0.4
12.3×12.8×5 12.3±0.4 12.8±0.4 5±0.3
12.3×25.4×4.9 12.3±0.4 25.4±0.5 4.9±0.3
12.35×12.7×5 12.35±0.4 12.7±0.4 5±0.3
12.5×12.7×5 12.5±0.4 12.7±0.4 5±0.3
12.5×15×8 12.5±0.5 15±0.6 8±0.4
12.5×16×6.7 12.5±0.4 16±0.4 6.7±0.3
12.5×20×8 12.5±0.5 20±0.6 8±0.4
12.7×15×7.9 12.7±0.5 15±0.6 7.9±0.4
12.7×16.7×7 12.7±0.5 16.7±0.6 7±0.4
12.7×16.5×7.9 12.7±0.5 16.5±0.6 7.9±0.4
12.7×17×7.9 12.7±0.4 17±0.4 7.9±0.3
12.7×18×8 12.7±0.5 18±0.6 8±0.4
12.7×25×7.9 12.7±0.4 25±0.5 7.9±0.3
12.7×25.4×7.9 12.7±0.5 25.4±0.6 7.9±0.4
12.8×15×8.4 12.8±0.5 15±0.5 8.4±0.4
13×15×7 13±0.5 15±0.4 7±0.3
13×20×5 13±0.5 20±0.6 5±0.4
13×28×8 13±0.5 28±0.7 8±0.4
14×15×5.6 14±0.4 15±0.4 5.6±0.3
14×15×7 14±0.5 15±0.5 7±0.4
14×15×9 14±0.5 15±0.5 9±0.5
14×15×10 14±0.5 15±0.5 10±0.5
14×16×10 14±0.4 16±0.4 10±0.4
14×17.5×6.5 14±0.4 17.5±0.4 6.5±0.3
14×18×10 14±0.5 18±0.6 10±0.5
14×22×10 14±0.5 22±0.6 10±0.5
14×24×3.8 14±0.4 24±0.5 3.8±0.3
14.2×15×6.7 14.2±0.5 15±0.5 6.7±0.4
14.2×15×7.2 14.2±0.5 15±0.5 7.2±0.4
14.2×15×8 14.2±0.5 15±0.5 8±0.4
14.2×15×9 14.2±0.5 15±0.5 9±0.5
14.2×15×10 14.2±0.4 15±0.4 10±0.4
14.2×15.6×6.35 14.2±0.4 15.6±0.4 6.35±0.3
14.2×18×6.35 14.2±0.4 18±0.4 6.35±0.3
14.2×18×6.5 14.2±0.5 18±0.5 6.5±0.4
14.2×18×10 14.2±0.4 18±0.4 10±0.4
14.2×19×6.35 14.2±0.4 19±0.4 6.35±0.3
14.2×20×6.35 14.2±0.5 20±0.5 6.35±0.4
14.2×20×7.2 14.2±0.5 20±0.5 7.2±0.4
14.2×20×9 14.2±0.4 20±0.5 9±0.3
14.2×20×10 14.2±0.4 20±0.5 10±0.4
14.2×23×8.2 14.2±0.4 23±0.5 8.2±0.3
14.2×23×7.5 14.2±0.5 23±0.6 7.5±0.4
14.2×23.5×6.7 14.2±0.5 23.5±0.6 6.7±0.4
14.2×23.5×8 14.2±0.5 23.5±0.6 8±0.4
14.2×23.5×9 14.2±0.4 23.5±0.5 9±0.3
14.2×24×6.35 14.2±0.4 24±0.5 6.35±0.3
14.2×24×9 14.2±0.5 24±0.6 9±0.5
14×24×9.5 14±0.5 24±0.6 9.5±0.5
14.2×25×7 14.2±0.4 25±0.5 7±0.3
14.2×25×7.5 14.2±0.5 25±0.6 7.5±0.4
14.2×25×8 14.2±0.5 25±0.6 8±0.4
14.2×25.5×6.35 14.2±0.4 25.5±0.5 6.35±0.3
14.2×25.5×9.5 14.2±0.5 25.5±0.6 9.5±0.5
14.2×26×6.35 14.2±0.4 26±0.5 6.35±0.3
14.2×28.5×4.5 14.2±0.5 28.5±0.7 4.5±0.4
14.2×28.5×5 14.2±0.4 28.5±0.5 5±0.3
14.2×28.5×5.2 14.2±0.4 28.5±0.5 5.2±0.3
14.2×28.5×5.5 14.2±0.5 28.5±0.7 5.5±0.4
14.2×28.5×6.35 14.2±0.5 28.5±0.7 6.35±0.4
14.2×28.5×7 14.2±0.5 28.5±0.7 7±0.4
14.2×28.5×7.2 14.2±0.5 28.5±0.7 7.2±0.4
14.2×28.5×8 14.2±0.5 28.5±0.7 8±0.4
14.2×28.5×8.3 14.2±0.5 28.5±0.7 8.3±0.4
14.2×28.5×9 14.2±0.5 28.5±0.7 9±0.5
14.2×28.5×9.5 14.2±0.5 28.5±0.7 9.5±0.5
14.2×28.5×10 14.2±0.5 28.5±0.7 10±0.5
14.2×30×8 14.2±0.5 30±1.0 8±0.4
15×35×5.9 15±0.5 35±1.0 5.9±0.4
15.5×19×7.3 15.5±0.4 19±0.4 7.3±0.3
15.5×28.5×7.3 15.5±0.5 28.5±0.7 7.3±0.4
15.7×27×9 15.7±0.5 27±0.7 9±0.5
15.88×25.6×7.86 15.88±0.5 25.6±0.7 7.86±0.4
16×17×8 16±0.5 17±0.5 8±0.4
16×17×9 16±0.5 17±0.5 9±0.5
16×17×10 16±0.5 17±0.5 10±0.5
16×17.3×4.5 16±0.4 17.3±0.4 4.5±0.3
16×17.5×4.3 16±0.5 17.5±0.5 4.3±0.4
16×18×8 16±0.4 18±0.4 8±0.3
16×20×5 16±0.4 20±0.5 5±0.3
16×20×7 16±0.4 20±0.5 7±0.3
16×20×8 16±0.5 20±0.5 8±0.4
16×20×9 16±0.5 20±0.5 9±0.5
16×20×10 16±0.4 20±0.5 10±0.4
16×22×10 16±0.4 22±0.5 10±0.4
16×24×7 16±0.4 24±0.5 7±0.3
16×24×9.5 16±0.4 24±0.5 9.5±0.4
16×25×5 16±0.4 25±0.5 5±0.3
16×25×7 16±0.4 25±0.5 7±0.3
16×25×8.2 16±0.4 25±0.5 8.2±0.3



Product packaging
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Advanced Technology Amorphous Transformer Core For Industrial Magnet 5
Huzhou Careful Magnetism Co., Ltd. is a technically leading corporation, integrating production, management, research, development and service. Our company was established in 2001, formally known as Huzhou Cifeng Industry Corporation - a key enterprise in Huzhou City. Our company was assessed as "High and New Technology Enterprise in Zhejiang Province". We have more than 20 years of experience in the field, as our boom development, now we own 3 factoies to service more and more clinets.
FAQ
1. Who are we?
We are based in Zhejiang, China, start from 2001,sell to Domestic Market(60.00%),Eastern Europe(10.00%),South Asia(5.00%),Eastern Asia(5.00%),North America(5.00%),Northern Europe(4.00%),South America(3.00%),Southern Europe(3.00%),Western Europe(2.00%),Oceania(1.00%),Central America(1.00%),Southeast Asia(1.00%). There are total about 1000+ people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;

3.What can you buy from us?
Soft Ferrite Core,Amorphous core,Inductors,nizn ferite

4. Why should you buy from us not from other suppliers?
we are the biggest manufacture of ferrite core in China for more than 30 years, also with production line of Amorphous core, SMD core, inductors for years. We are already the supplier of Microsoft,GREE, Midea, SAMSUNG, ASUS, Panasonic, etc.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery; Accepted Payment Currency: USD, CNY; Accepted Payment Type: T/T, L/C, PayPal, Western Union, Escrow; Language Spoken: English, Chinese
Advanced Technology Amorphous Transformer Core For Industrial Magnet 6

Good price  online

Products Details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Nanocrystalline Core
Created with Pixso. Advanced Technology Amorphous Transformer Core For Industrial Magnet

Advanced Technology Amorphous Transformer Core For Industrial Magnet

Brand Name: CAREFUL
Model Number: UT
MOQ: 1000 pieces
Price: $0.50-12.56/pieces
Packaging Details: Certain pieces of items into one polybag, several polybags into one export carton.
Pallet could be arranged if required!
Detail Information
Place of Origin:
Zhejiang, China
Brand Name:
CAREFUL
Certification:
RoHS
Model Number:
UT
Features:
Industrial Magnet
Type:
Wireless Charging Coils
Application:
Industrial Magnet
Brand:
Careful
Supplier Type:
Factory
Tolerance:
20%
Package Type:
Carton
Media Available:
Careful Catalog
Function:
Industrial Magnet
Mounting Type:
Through Hole
Package / Case:
Carton
Material - Core:
Amorphous
Sample:
Free Charge
Material:
Many For Selection
MOQ:
10 Pcs
Package:
Carton
AL:
2-5000
Minimum Order Quantity:
1000 pieces
Price:
$0.50-12.56/pieces
Packaging Details:
Certain pieces of items into one polybag, several polybags into one export carton.
Pallet could be arranged if required!
Supply Ability:
100000 Piece/Pieces per Month
Highlight:

advanced amorphous core

,

advanced amorphous transformer core

,

industrial amorphous core

Product Description
China factory careful company Advanced technology Amorphous transformer core

Products Description
Advanced Technology Amorphous Transformer Core For Industrial Magnet 0
Advanced Technology Amorphous Transformer Core For Industrial Magnet 1
Advanced Technology Amorphous Transformer Core For Industrial Magnet 2
Advanced Technology Amorphous Transformer Core For Industrial Magnet 3
Advanced Technology Amorphous Transformer Core For Industrial Magnet 4
Item
Value
Place of Origin
China

Zhejiang
Brand Name
Careful
Model Number
T
Type
Soft
Composite
Amorphous
Shape
Coil
Application
Industrial Magnet
Tolerance
±10%
Certificates
ISO9001-2015
Permeability
>100000
Material
Amorphous&Nanocrystalline





RH Specifications Dimensions:mm
A B C
10×17.5×5 10±0.4 17.5±0.5 5±0.4
10×20×4.2 10±0.4 20±0.5 4.2±0.4
10×20×5 10±0.4 20±0.5 5±0.4
10×20×5.5 10±0.4 20±0.5 5.5±0.4
10×20×6 10±0.4 20±0.5 6±0.4
10×20×6.35 10±0.4 20±0.5 6.35±0.4
10×20×6.5 10±0.4 20±0.5 6.5±0.3
10×23×5 10±0.4 23±0.5 5±0.3
10×23×6.5 10±0.4 23±0.5 6.5±0.3
10×25×5.5 10±0.4 25±0.6 5.5±0.4
10.1×11.5×6.5 10.1±0.4 11.5±0.4 6.5±0.3
10.1×13.5×6.35 10.1±0.4 13.5±0.4 6.35±0.3
10.3×11.5×5 10.3±0.4 11.5±0.5 5±0.4
10.5×12×5.5 10.5±0.4 12±0.5 5.5±0.4
10.5×13.5×6.5 10.5±0.4 13.5±0.5 6.5±0.4
10.5×14×6 10.5±0.4 14±0.5 6±0.4
10.5×14×7.3 10.5±0.4 14±0.5 7.3±0.4
10.5×15×5.6 10.5±0.4 15±0.5 5.6±0.4
10.5×15×6.5 10.5±0.4 15±0.4 6.5±0.3
10.5×15×7.3 10.5±0.4 15±0.5 7.3±0.4
10.5×20×5.5 10.5±0.4 20±0.5 5.5±0.4
10.5×20×6 10.5±0.4 20±0.5 6±0.4
10.5×20×6.5 10.5±0.4 20±0.5 6.5±0.4
10.5×20×7.3 10.5±0.4 20±0.5 7.3±0.4
10.5×25×5.6 10.5±0.4 25±0.5 5.6±0.3
10.5×25×6.5 10.5±0.4 25±0.5 6.5±0.3
10.5×28.5×5.5 10.5±0.4 28.5±0.7 5.5±0.4
10.5×30×6.5 10.5±0.4 30±0.6 6.5±0.4
11×13×7.5 11±0.4 13±0.4 7.5±0.3
11×20×5 11±0.5 20±0.5 5±0.4
11×25×5 11±0.5 25±0.6 5±0.4
11×30×5 11±0.4 30±0.6 5±0.3
11.5×18.5×5 11.5±0.5 18.5±0.5 5±0.4
11.5×19.5×5.6 11.5±0.4 19.5±0.4 5.6±0.3
11.5×20×5 11.5±0.5 20±0.5 5±0.4
11.5×20.5×5 11.5±0.4 20.5±0.5 5±0.3
11.5×23×5.2 11.5±0.4 23±0.5 5.2±0.3
11.5×25×5 11.5±0.5 25±0.6 5±0.4
11.5×30×5 11.5±0.5 30±0.6 5±0.4
11.8×15×5 11.8±0.4 15±0.4 5±0.3
11.8×15×7.3 11.8±0.5 15±0.5 7.3±0.4
11.8×15×7.5 11.8±0.4 15±0.4 7.5±0.3
11.8×20×5 11.8±0.4 20±0.5 5±0.3
12×12.5×8.5 12±0.5 12.5±0.5 8.5±0.4
12×12.7×5.6 12±0.4 12.7±0.4 5.6±0.3
12×12.7×6 12±0.5 12.7±0.5 6±0.4
12×12.7×6.5 12±0.5 12.7±0.5 6.5±0.4
12×13×8 12±0.5 13±0.5 8±0.4
12×13.8×6.5 12±0.4 13.8±0.4 6.5±0.3
12×14×6 12±0.4 14±0.4 6±0.3
12×15×5.5 12±0.5 15±0.5 5.5±0.4
12×15.5×5.6 12±0.5 15.5±0.5 5.6±0.4
12×15×6.5 12±0.5 15±0.5 6.5±0.4
12×15×7.3 12±0.5 15±0.5 7.3±0.4
12×15×8 12±0.5 15±0.5 8±0.4
12×15×8.5 12±0.5 15±0.5 8.5±0.5
12×15.5×8 12±0.4 15.5±0.4 8±0.3
12×16.5×6.5 12±0.5 16.5±0.5 6.5±0.4
12×16×8.5 12±0.4 16±0.4 8.5±0.3
12×17.5×6.5 12±0.5 17.5±0.6 6.5±0.4
12×19×5.6 12±0.5 19±0.6 5.6±0.4
12×20×3.5 12±0.5 20±0.6 3.5±0.4
12×20×3.6 12±0.5 20±0.6 3.6±0.4
12×20×4 12±0.5 20±0.5 4±0.4
12×20×4.5 12±0.5 20±0.5 4.5±0.4
12×20×5 12±0.5 20±0.5 5±0.4
12×20×5.2 12±0.4 20±0.5 5.2±0.3
12×20×5.6 12±0.5 20±0.5 5.6±0.4
12×20×5.8 12±0.4 20±0.5 5.8±0.3
12×20×6 12±0.5 20±0.5 6±0.4
12×20×6.5 12±0.5 20±0.5 6.5±0.4
12×20×7 12±0.4 20±0.5 7±0.3
12×20×7.3 12±0.5 20±0.5 7.3±0.4
12×20×8.5 12±0.5 20±0.5 8.5±0.4
12×21×6.5 12±0.4 21±0.5 6.5±0.3
12×22×5.6 12±0.4 22±0.5 5.6±0.3
12×23×3.5 12±0.5 23±0.6 3.5±0.4
12×23×4.5 12±0.5 23±0.6 4.5±0.4
12×23×5.6 12±0.5 23±0.6 5.6±0.4
12×23×6.5 12±0.5 23±0.6 6.5±0.4
12×23×7.9 12±0.5 23±0.6 7.9±0.4
12×24.5×5.6 12±0.5 24.5±0.6 5.6±0.4
12×25×3.5 12±0.4 25±0.5 3.5±0.3
12×25×4.5 12±0.4 25±0.5 4.5±0.3
12×25×5.6 12±0.5 25±0.6 5.6±0.4
12×25×6.4 12±0.4 25±0.5 6.4±0.3
12×25×6.5 12±0.4 25±0.5 6.5±0.3
12×25×7.3 12±0.5 25±0.6 7.3±0.4
12×25.4×5.2 12±0.5 25.4±0.6 5.2±0.4
12×25.4×6.5 12±0.4 25.4±0.5 6.5±0.3
12×25.5×5.6 12±0.4 25.5±0.5 5.6±0.3
12×26×4.5 12±0.4 26±0.5 4.5±0.3
12×26×7.3 12±0.5 26±0.7 7.3±0.4
12×27×7.9 12±0.4 27±0.5 7.9±0.3
12×28.5×5.6 12±0.5 28.5±0.7 5.6±0.4
12×28.5×6.5 12±0.5 28.5±0.7 6.5±0.4
12×28.5×8 12±0.5 28.5±0.7 8±0.4
12×30×5 12±0.5 30±1 5±0.4
RH Specifications Dimensions:mm
A B C
12×30×5.6 12±0.5 30±1 5.6±0.4
12×30×8 12±0.4 30±0.6 8±0.3
12×32×6 12±0.4 32±0.6 6±0.3
12×40×6 12±0.5 40±0.7 6±0.4
12.1×15.5×7.3 12.1±0.5 15.5±0.5 7.3±0.4
12.2×27×7.9 12.2±0.5 27±0.7 7.9±0.4
12.2×28.5×7.9 12.2±0.5 28.5±0.7 7.9±0.4
12.3×12.5×5 12.3±0.5 12.5±0.5 5±0.4
12.3×12.8×5 12.3±0.4 12.8±0.4 5±0.3
12.3×25.4×4.9 12.3±0.4 25.4±0.5 4.9±0.3
12.35×12.7×5 12.35±0.4 12.7±0.4 5±0.3
12.5×12.7×5 12.5±0.4 12.7±0.4 5±0.3
12.5×15×8 12.5±0.5 15±0.6 8±0.4
12.5×16×6.7 12.5±0.4 16±0.4 6.7±0.3
12.5×20×8 12.5±0.5 20±0.6 8±0.4
12.7×15×7.9 12.7±0.5 15±0.6 7.9±0.4
12.7×16.7×7 12.7±0.5 16.7±0.6 7±0.4
12.7×16.5×7.9 12.7±0.5 16.5±0.6 7.9±0.4
12.7×17×7.9 12.7±0.4 17±0.4 7.9±0.3
12.7×18×8 12.7±0.5 18±0.6 8±0.4
12.7×25×7.9 12.7±0.4 25±0.5 7.9±0.3
12.7×25.4×7.9 12.7±0.5 25.4±0.6 7.9±0.4
12.8×15×8.4 12.8±0.5 15±0.5 8.4±0.4
13×15×7 13±0.5 15±0.4 7±0.3
13×20×5 13±0.5 20±0.6 5±0.4
13×28×8 13±0.5 28±0.7 8±0.4
14×15×5.6 14±0.4 15±0.4 5.6±0.3
14×15×7 14±0.5 15±0.5 7±0.4
14×15×9 14±0.5 15±0.5 9±0.5
14×15×10 14±0.5 15±0.5 10±0.5
14×16×10 14±0.4 16±0.4 10±0.4
14×17.5×6.5 14±0.4 17.5±0.4 6.5±0.3
14×18×10 14±0.5 18±0.6 10±0.5
14×22×10 14±0.5 22±0.6 10±0.5
14×24×3.8 14±0.4 24±0.5 3.8±0.3
14.2×15×6.7 14.2±0.5 15±0.5 6.7±0.4
14.2×15×7.2 14.2±0.5 15±0.5 7.2±0.4
14.2×15×8 14.2±0.5 15±0.5 8±0.4
14.2×15×9 14.2±0.5 15±0.5 9±0.5
14.2×15×10 14.2±0.4 15±0.4 10±0.4
14.2×15.6×6.35 14.2±0.4 15.6±0.4 6.35±0.3
14.2×18×6.35 14.2±0.4 18±0.4 6.35±0.3
14.2×18×6.5 14.2±0.5 18±0.5 6.5±0.4
14.2×18×10 14.2±0.4 18±0.4 10±0.4
14.2×19×6.35 14.2±0.4 19±0.4 6.35±0.3
14.2×20×6.35 14.2±0.5 20±0.5 6.35±0.4
14.2×20×7.2 14.2±0.5 20±0.5 7.2±0.4
14.2×20×9 14.2±0.4 20±0.5 9±0.3
14.2×20×10 14.2±0.4 20±0.5 10±0.4
14.2×23×8.2 14.2±0.4 23±0.5 8.2±0.3
14.2×23×7.5 14.2±0.5 23±0.6 7.5±0.4
14.2×23.5×6.7 14.2±0.5 23.5±0.6 6.7±0.4
14.2×23.5×8 14.2±0.5 23.5±0.6 8±0.4
14.2×23.5×9 14.2±0.4 23.5±0.5 9±0.3
14.2×24×6.35 14.2±0.4 24±0.5 6.35±0.3
14.2×24×9 14.2±0.5 24±0.6 9±0.5
14×24×9.5 14±0.5 24±0.6 9.5±0.5
14.2×25×7 14.2±0.4 25±0.5 7±0.3
14.2×25×7.5 14.2±0.5 25±0.6 7.5±0.4
14.2×25×8 14.2±0.5 25±0.6 8±0.4
14.2×25.5×6.35 14.2±0.4 25.5±0.5 6.35±0.3
14.2×25.5×9.5 14.2±0.5 25.5±0.6 9.5±0.5
14.2×26×6.35 14.2±0.4 26±0.5 6.35±0.3
14.2×28.5×4.5 14.2±0.5 28.5±0.7 4.5±0.4
14.2×28.5×5 14.2±0.4 28.5±0.5 5±0.3
14.2×28.5×5.2 14.2±0.4 28.5±0.5 5.2±0.3
14.2×28.5×5.5 14.2±0.5 28.5±0.7 5.5±0.4
14.2×28.5×6.35 14.2±0.5 28.5±0.7 6.35±0.4
14.2×28.5×7 14.2±0.5 28.5±0.7 7±0.4
14.2×28.5×7.2 14.2±0.5 28.5±0.7 7.2±0.4
14.2×28.5×8 14.2±0.5 28.5±0.7 8±0.4
14.2×28.5×8.3 14.2±0.5 28.5±0.7 8.3±0.4
14.2×28.5×9 14.2±0.5 28.5±0.7 9±0.5
14.2×28.5×9.5 14.2±0.5 28.5±0.7 9.5±0.5
14.2×28.5×10 14.2±0.5 28.5±0.7 10±0.5
14.2×30×8 14.2±0.5 30±1.0 8±0.4
15×35×5.9 15±0.5 35±1.0 5.9±0.4
15.5×19×7.3 15.5±0.4 19±0.4 7.3±0.3
15.5×28.5×7.3 15.5±0.5 28.5±0.7 7.3±0.4
15.7×27×9 15.7±0.5 27±0.7 9±0.5
15.88×25.6×7.86 15.88±0.5 25.6±0.7 7.86±0.4
16×17×8 16±0.5 17±0.5 8±0.4
16×17×9 16±0.5 17±0.5 9±0.5
16×17×10 16±0.5 17±0.5 10±0.5
16×17.3×4.5 16±0.4 17.3±0.4 4.5±0.3
16×17.5×4.3 16±0.5 17.5±0.5 4.3±0.4
16×18×8 16±0.4 18±0.4 8±0.3
16×20×5 16±0.4 20±0.5 5±0.3
16×20×7 16±0.4 20±0.5 7±0.3
16×20×8 16±0.5 20±0.5 8±0.4
16×20×9 16±0.5 20±0.5 9±0.5
16×20×10 16±0.4 20±0.5 10±0.4
16×22×10 16±0.4 22±0.5 10±0.4
16×24×7 16±0.4 24±0.5 7±0.3
16×24×9.5 16±0.4 24±0.5 9.5±0.4
16×25×5 16±0.4 25±0.5 5±0.3
16×25×7 16±0.4 25±0.5 7±0.3
16×25×8.2 16±0.4 25±0.5 8.2±0.3



Product packaging
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Advanced Technology Amorphous Transformer Core For Industrial Magnet 5
Huzhou Careful Magnetism Co., Ltd. is a technically leading corporation, integrating production, management, research, development and service. Our company was established in 2001, formally known as Huzhou Cifeng Industry Corporation - a key enterprise in Huzhou City. Our company was assessed as "High and New Technology Enterprise in Zhejiang Province". We have more than 20 years of experience in the field, as our boom development, now we own 3 factoies to service more and more clinets.
FAQ
1. Who are we?
We are based in Zhejiang, China, start from 2001,sell to Domestic Market(60.00%),Eastern Europe(10.00%),South Asia(5.00%),Eastern Asia(5.00%),North America(5.00%),Northern Europe(4.00%),South America(3.00%),Southern Europe(3.00%),Western Europe(2.00%),Oceania(1.00%),Central America(1.00%),Southeast Asia(1.00%). There are total about 1000+ people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;

3.What can you buy from us?
Soft Ferrite Core,Amorphous core,Inductors,nizn ferite

4. Why should you buy from us not from other suppliers?
we are the biggest manufacture of ferrite core in China for more than 30 years, also with production line of Amorphous core, SMD core, inductors for years. We are already the supplier of Microsoft,GREE, Midea, SAMSUNG, ASUS, Panasonic, etc.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery; Accepted Payment Currency: USD, CNY; Accepted Payment Type: T/T, L/C, PayPal, Western Union, Escrow; Language Spoken: English, Chinese
Advanced Technology Amorphous Transformer Core For Industrial Magnet 6
